AES Global e-LOOP EL00C-RAD Loops – Commercial / Presence Mode

The E-loop commercial is the epitome of perfection when it comes to wireless vehicle detection systems designed specifically for commercial settings.

With its wireless nature, installation becomes a breeze, eliminating the need for complex wiring systems and minimizing disruption to the existing infrastructure. Moreover, the system’s efficient energy consumption and low maintenance needs make it a cost-effective solution that ensures long-term reliability.

Additionally, the E-loop commercial is available with a convenient presence mode, which intelligently keeps gates and barriers open for an extended duration when longer vehicles are in motion over the detection area. This advanced functionality enhances safety and efficiency by minimizing interruptions and reducing the risk of collisions, further solidifying its suitability for commercial environments.

EL00C-RAD

• Presence mode
• Quick and easy installation
• Magnetic field detection
• 10600 mA battery gives up to 6-10 years of battery life
• Made of high-impact plastic – 10 tonne static load limit
• Range up to 50 yards
• Compact profile – only 1.1″ high x 8.6″ diameter (IP68)
• High-security 128-bit encryption
• Kits include e-Loop, transceiver, magnet & concrete fixing bolts

e-Trans50

Introducing a bidirectional wireless access control system for gate and door applications.

• Compact design with exceptional range
• SMA connector for standard for optional long-range antenna connection
• Wide Voltage Range: 10-36V DC
• Exceptionally low Current draw: standby 4.5 m/a, active 30 m/a
• Frequency: 433.39 MHz
• Remote storage: 50 remotes, 4 x e-Loops, 4 x Keypads, 4 x Entry Buttons
• Relay: 1-amp contact rating, COM and N/O connections x 1 relay
• Multiple Modes: Pulse, Latch and Hold

e-Trans100

Two Channel Transceiver.

• 2 channel transceiver
• Long range with SMA connector for external antenna options
• Stores 2 x e-Loops and 50 x remotes in each channel
• 10-28VAC or 10-36VDC power input
• Low current draw 12mA in standby, can be set to LDC mode
• 4.5mA for solar applications
• 433.39 MHz frequency
• 250 Hz bandwidth
• 128bit AES encryption for total security
• 2 x 1A relay contacts
• NC/NO/COM outputs
• Can be set to pulse latch or hold mode
• Suspension inputs for each relay

e-Trans200

With a unique lock-out function, this high-end accessory is designed to manage access control for commercial multi-unit complexes with up to 200 units, with functions also suitable for home systems.

• Simple to use menu functions with LCD display
• High sensitivity 433 MHz -126 dBm receiver with 20 dBm Transmission output
• External SMA connector to allow for the connection of different antennas
• Wide input voltage range from 10V to 36V ACDC
• 2 relay outputs with the ability to set to Pulse, Hold or Latch mode
• Selectable ultra-low standby power consumption of only 4.5 m/a making it ideal for solar applications
• 200 code storage with remote ID selection making it ideal for unit applications
• Ability to delete individual remote devices
• Unique lock-out feature allowing you to lock out entry buttons, e-Loops and keypads using the lock and unlock function on the e-Remote
• Ability to connect to the e-Loop to access menus and change settings
• Test mode allows you to test relay outputs, signal strength, and interference

e-TransPlus Plugin

Get more out of the e-Loop by connecting the e-Trans-plus plug-in. This device plugs into our latest I-gate unit the I-Gate-Plus, which gives the user extra features.

• Set auto relay times
• Set do not disturb times
• SMS low battery notification
• Set e-Loop lock out times
• Program mode
