DoorKing 1602 Barrier Gate Operator – Wishbone – 27′

Description

The 1602 operator is designed for traffic lanes up to 27-feet wide in low use commercial and industrial applications — typical applications are industrial sites and loading dock areas, and is designed to control wide traffic lanes. This operator uses a counter-balanced three-piece wishbone style arm assembly. The heavy-duty Harmonic Arm Linkage assures smooth and accurate Arm travel of 90° in approximately 5.5 seconds. The 1602 operator is designed so that it can be mounted on either the left or right hand side of the roadway. The operator can be equipped with a DC convenience open package (optional) that will automatically raise the arm in the event of a power outage.

The DoorKing 1602 Barrier Gate Operator Accommodates Several Barrier Arm Styles (Sold Separately). To complete your purchase of the DoorKing 1602,

1. Choose an Operator
2. Choose a Barrier Arm
3. If Purchasing the Wooden Arm, the Doorking 1602-041 Hardware Kit is Required

Features

• Magnetic limit control
• Ports for plug-in loop detectors
• Automatic sequencing inputs for use with slide and swing gate operators
• Up input memory buffer
• Down memory option
• Multiple up commands
• Two convenience outlets
• Gate tracker reporting output
• Programming switches
• Built-in power On/Off switch
• Left or right hand mount
• 1 HP continuous-duty motor
• 115, 230*, 460* VAC. (*230 and 460 volt units use a step-down power transformer to achieve 115 volt operating voltage.)
• 60:1 gear-box running in a continuous oil bath
• Arm rotates 90° in approximately 5.5 seconds
• Class III and IV applications
• Compliant with UL 325 and 991. ETL Listed.
• MADE IN USA

Options

• Aluminum arms: 20 Feet, 24 Feet, 27 Feet
• Aluminum arms LED Lighted: 20 Feet, 24 Feet, 27 Feet
• 20-Foot Wood Arm (requires 1602-041 kit)
• DKS Pedestrian Protection System
• Plug-in loop detectors
• DC powered convenience open
• Heater kit
• Fan kit
• Surge suppressors
• Manual Crank kit
